Model | Cooling capacity | Outlet Temperature | Input Power | COP | IPLV | Rated speed | Power Supply | Evaporator Water Flow | Pressure Drop |
DK-CXF | kW | RT | ℃ | kW | W/W | W/W | rpm | kW | m³/h | kPa |
250SG-3MM | 880 | 250 | -7~0 | 217.5 | 4.05 |
| 15000 | 261 | 168 | 81 |
300SG-3MM | 1055 | 300 | -7~0 | 254.9 | 4.14 |
| 15400 | 306 | 202 | 89 |
250SG-3MZ | 880 | 250 | -2~5 | 184.4 | 4.77 |
| 13700 | 221 | 168 | 76 |
300SG-3MZ | 1055 | 300 | -2~5 | 212.0 | 4.98 |
| 13900 | 254 | 202 | 84 |
350SG-3MZ | 1230 | 350 | 2~5 | 245.1 | 5.02 | \ | 14400 | 294 | 235 | 84 |
250SW-3LS | 880 | 250 | 5~20 | 136.9 | 6.42 | 8.17 | 13800 | 164 | 151 | 81 |
300SW-3LS | 1055 | 300 | 5~20 | 163.3 | 6.46 | 8.65 | 14400 | 196 | 181 | 84 |
350SW-3LS | 1230 | 350 | 5~20 | 195.0 | 6.31 | 8.92 | 15200 | 234 | 212 | 87 |
400SW-4LS | 1406 | 400 | 5~20 | 220.9 | 6.37 | 8.79 | 12900 | 265 | 242 | 84 |
450SW-4LS | 1582 | 450 | 5~20 | 241.0 | 6.57 | 9.17 | 13300 | 289 | 272 | 85 |
500SW-5LS | 1758 | 500 | 5~20 | 268.4 | 6.55 | 9.40 | 13700 | 322 | 302 | 82 |
550SW-5LS | 1934 | 550 | 5~20 | 300.4 | 6.44 | 9.54 | 14100 | 360 | 333 | 81 |
600SW-6LS | 2110 | 600 | 5~20 | 306.2 | 6.89 | 9.34 | 11900 | 367 | 363 | 81 |
700SW-7LS | 2462 | 700 | 5~20 | 366.9 | 6.71 | 9.68 | 12600 | 440 | 423 | 81 |
800SW-7LS | 2813 | 800 | 5~20 | 430.6 | 6.53 | 9.84 | 13100 | 517 | 484 | 80 |
900DW-5LS | 3165 | 900 | 5~20 | 235.3*2 | 6.72 | 9.70 | 13300 | 282*2 | 544 | 70 |
1000DW-5LS | 3517 | 1000 | 5~20 | 265.9*2 | 6.61 | 9.65 | 13700 | 319*2 | 605 | 70 |
1100DW-5LS | 3869 | 1100 | 5~20 | 304.2*2 | 6.36 | 9.71 | 14100 | 365*2 | 665 | 70 |
1200DW-6LS | 4220 | 1200 | 5~20 | 306.2*2 | 6.89 | 9.96 | 11900 | 367*2 | 726 | 70 |
1300DW-6LS | 4572 | 1300 | 5~20 | 335.5*2 | 6.81 | 9.86 | 12200 | 402*2 | 786 | 70 |
1400DW-7LS | 4924 | 1400 | 5~20 | 366.9*2 | 6.71 | 9.98 | 12600 | 440*2 | 847 | 70 |
1500DW-7LS | 5275 | 1500 | 5~20 | 399.1*2 | 6.61 | 10.05 | 13000 | 478*2 | 907 | 70 |
1600TW-5LS | 5626 | 1600 | 5~20 | 289.2*3 | 6.48 | 9.81 | 13900 | 347*3 | 968 | 63 |
1700TW-5LS | 5979 | 1700 | 5~20 | 311.9*3 | 6.39 | 9.75 | 14200 | 374*3 | 1028 | 70 |
1800TW-6LS | 6331 | 1800 | 5~20 | 306.1*3 | 6.89 | 10.19 | 11900 | 367*3 | 1089 | 73 |
1900TW-6LS | 6682 | 1900 | 5~20 | 325.5*3 | 6.84 | 10.21 | 12100 | 390*3 | 1149 | 80 |
2000TW-7LS | 7033 | 2000 | 5~20 | 346.9*3 | 6.78 | 10.19 | 12300 | 416*3 | 1210 | 74 |
2100TW-7LS | 7385 | 2100 | 5~20 | 366.9*3 | 6.71 | 10.15 | 12600 | 440*3 | 1270 | 81 |
2200TW-7LS | 7737 | 2200 | 5~20 | 388.3*3 | 6.64 | 10.09 | 12800 | 465*3 | 1330 | 74 |
2300TW-7LS | 8089 | 2300 | 5~20 | 409.8*3 | 6.58 | 9.99 | 13100 | 491*3 | 1391 | 79 |
Note:
1. The parameters of the normal temperature unit in the table are given according to the national standard G8T18430.-2007. Working conditions: cooling water outlet temperature T, water flow rate = cooling capacity 0.172m/h; cooling water temperature 30℃, water flow rate = cooling capacity x 0.215m3/(h·kW);
2. The energy efficiency level of normal temperature units is based on the standard: GB19572015 (Energy efficiency limit values and energy efficiency ratings for chillers);
3. Low temperature unit working conditions: the refrigerant is ethylene dichloride with a volumetric filling rate of 30%, the outlet water temperature of the cooling water is 0℃/-5℃, the ethylene dichloride waste water production = cooling capacity 0191m3 (h·kw): cooling water inlet temperature 30C, water flow rate = cooling capacity 0215m3 (h·kw);
4. The water side pressure of the evaporator and condenser is 10MPa. If the working pressure is higher than 1.0MPa, it should be indicated when ordering;
5. The power supply is 380M3P50HZ, the compressor starting current is 2A, and the unit uses refrigerant R134a
6. Due to product improvement and optimization, the above parameters may be changed. Please refer to the product nameplate:
7. The company's product models are being expanded. If you have other requirements, please consult the technicians for details.
Model | Chilled Pipe Dia | Condenser Water flow | Pressure Drop | Cooling Water dia | L | W | H | Weight | Running Weight |
DK-CXF | DN(mm) | m/h | kPa | DN(mm) | mm | mm | mm | kg | kg |
250SG-3MM | 200 | 189 | 72 | 200 | 4352 | 1960 | 2068 | 6000 | 6630 |
300SG-3MM | 200 | 227 | 64 | 200 | 4352 | 2070 | 2068 | 6100 | 6770 |
250SG-3MZ | 200 | 189 | 72 | 200 | 4352 | 1960 | 2068 | 6000 | 6630 |
300SG-3MZ | 200 | 227 | 64 | 200 | 4352 | 2070 | 2068 | 6100 | 6770 |
350SG-3MZ | 200 | 265 | 72 | 200 | 4352 | 2070 | 2068 | 6250 | 7040 |
250SW-3LS | 200 | 189 | 72 | 200 | 4275 | 1701 | 1818 | 5200 | 5770 |
300SW-3LS | 200 | 227 | 64 | 200 | 4275 | 1701 | 1818 | 5200 | 5870 |
350SW-3LS | 200 | 265 | 72 | 200 | 4275 | 1701 | 1818 | 6000 | 6790 |
400SW-4LS | 200 | 302 | 72 | 200 | 4296 | 1808 | 1887 | 6000 | 6890 |
450SW-4LS | 250 | 340 | 72 | 250 | 4352 | 2070 | 2375 | 6800 | 7810 |
500SW-5LS | 250 | 378 | 72 | 250 | 4360 | 2103 | 1980 | 6800 | 7930 |
550SW-5LS | 250 | 416 | 71 | 250 | 4360 | 2103 | 1980 | 6800 | 8030 |
600SW-6LS | 300 | 454 | 72 | 300 | 4352 | 2070 | 2375 | 7600 | 8970 |
700SW-7LS | 300 | 529 | 72 | 300 | 5111 | 2276 | 2370 | 8200 | 9790 |
800SW-7LS | 300 | 605 | 70 | 300 | 5111 | 2276 | 2370 | 8680 | 10520 |
900DW-5LS | 350 | 680 | 70 | 350 | 5700 | 2600 | 2300 | 9680 | 11920 |
1000DW-5LS | 350 | 756 | 70 | 350 | 5700 | 2600 | 2300 | 9940 | 12440 |
1100DW-5LS | 350 | 832 | 70 | 350 | 5700 | 2600 | 2300 | 10210 | 12950 |
1200DW-6LS | 400 | 907 | 70 | 400 | 5900 | 3200 | 2700 | 11520 | 14510 |
1300DW-6LS | 400 | 983 | 70 | 400 | 5900 | 3200 | 2700 | 11780 | 15020 |
1400DW-7LS | 400 | 1058 | 70 | 400 | 5900 | 3300 | 2800 | 12060 | 15550 |
1500DW-7LS | 400 | 1134 | 70 | 400 | 5900 | 3300 | 2800 | 12320 | 16060 |
1600TW-5LS | 450 | 1210 | 69 | 450 | 5800 | 2800 | 2400 | 13800 | 17960 |
1700TW-5LS | 450 | 1285 | 70 | 450 | 5800 | 2800 | 2400 | 13800 | 18040 |
1800TW-6LS | 450 | 1361 | 58 | 450 | 7900 | 3200 | 3100 | 15280 | 19080 |
1900TW-6LS | 450 | 1436 | 63 | 450 | 7900 | 3200 | 3100 | 15280 | 19160 |
2000TW-7LS | 450 | 1512 | 58 | 450 | 7900 | 3200 | 3100 | 15890 | 20110 |
2100TW-7LS | 450 | 1587 | 63 | 450 | 7900 | 3200 | 3100 | 15890 | 20190 |
2200TW-7LS | 450 | 1663 | 58 | 450 | 7900 | 3200 | 3100 | 16440 | 21090 |
2300TW-7LS | 450 | 1739 | 62 | 450 | 7900 | 3200 | 3100 | 16440 | 21170 |
